EZ-Roll T-Leg - Black

EZ-Roll T-Leg

Traditional

Price From:

$223 List

T-Leg with concealed EZ-Roll wheels is stationary or can be mobile when titled. Fabricated 14 gauge 2" diameter columns with steel endcaps and EZ-Roll wheels.

  • Unit height: 27.75"
  • Welded Mounting Plate: 5" x 8" x 7/32 steel; require 14 #12 screws
  • Column: 2" diameter
  • Base Spread: 16", 22", 26"
  • EZ Roll Wheels: 1.5" diameter built-in plastic wheels
  • Finish: powder coat; black is stock color
  • Packaging: 2 legs per box, priced individually
Show More
Item Details
Related Products
Specifications
Shipping & Payment
Warranty & Returns
Resources & Downloads

Specifications

Unit Height 27.75"
Height Options Custom Height between 5" - 28.99"
Column Diameter 2"
Welded Mounting Plate 5" x 8" x 7/32" steel; require 14 #12 screws
Base Spread 16", 22", 26"
EZ Roll Wheels 1.5" diameter built-in plastic wheels
Method of Assembly Bolted construction
Finish Powder coat; black is stock color
Packaging 2 legs per box, priced individually

Size Chart

Base SpreadColumn DiameterMounting PlateRecommended Top Size
16"2"5" x 8"20"-22"D x 30"-120"W
22"2"5" x 8"24"-28"D x 30"-96"W
26"2"5" x 8"28"-30"D x 42"-96"W

.

Resources & Downloads

EZ-Roll T-Leg 360o View
